Coswheel GT20 Max
Full suspension ebike for limitless adventures
Video
GT20 Max Specifications
Tips : GT20 Max model have CE and COC certificates. The speed of GT20 Max ebikes shipped to Europe will be limited to 25km/h when they leave the factory. After receiving the bike, you can contact us for guidance on lifting the speed limit. We can also send you a 250W logo to be affixed to the motor in accordance with European regulations.At present, European customers have not reported any regulatory issues after riding
Performance
- Top Speed: The Initial Speed limit 25Km/h，Class 2/3 can unlock off-road mode
- Range: 80+miles (128km) in Class-2 throttle-only mode (pure electricity); 145miles (233km) in Class-1 PAS (pedal assist)
- Motor: 60V Peak 2000 (Rated 1500) Brushless Rear Hub Motor
- Torque：120N.m
- Battery: 60V 25Ah+15Ah Samsung Battery (Lithium 18650 Cells)
- Energy: 2400Wh
- Front Suspension: 20" Shoulder Shock Absorbing, 80mm Travel
- Rear Suspension: 850 Pounds, 180mm Travel
- Brakes: Double Piston Oil Brake, Equipped with 180mm Stainless Brake Disc
- Tires: ARISUN Off Road Tire 20" × 4.0" A820 60TPI with Meimeng Tire+PVC Line
- Throttle: Thumb Throttle
Electronics
- Charger: 60V5A Charger
- Charging Time: 3.5-8.0 Hours
- Display: Easy Read LCD Display
- Controller: 60V 35A
- Front Light: Classic Angel Eye Headlight, 120 LUX
- Rear Light: LED
- Pedal Assist: 3 Levels
- Sensors: Speed Sensor
Components
- Frame: Hydroformed Triple-Butted 6061-T6 Aluminium Alloy
- Pedal: Aluminum Alloy Pedal, with Reflect-light, Axis 9/16 x2
- Crank: 1/2 "*3/32"*46T 7-speed ED Tooth Plate
- Rear Derailleur: Shimano 7-Speed
- Chain: 7-speed Anti-rust, 1/2" * 3/32"
- Handlebars: Split Handlebar, φ32 φ22 Sand Black
Geometry
- Suitable Height: 5'1" - 6'5"
- Seat Height: 32.6" (83cm)
- Bike Height: 41.7" (106cm)
- Wheelbase: 47.8" (121.5cm)
- Handlebar Width: 27.2" (69cm)
- Bike Weight: ≥99lbs (with Battery) (≥45kg)
- Maximum Load: 330lbs (150kg)
- Safe Load: 265lbs (120kg)
- Overall Size: 70.9" * 27.2" *41.7" (180*69*106cm)
- Package Size: 59.4" * 13.8" * 36.2" (151*35*92cm)
GT20 Max features in detail
Equipped with 60V 1500 rated power outputs max 2000 powerful power, Class 2/3 can unlock off-road mode, making climbing You'll experience the double power, provide you with an awesome riding experience(To comply with European regulations, the motor power can be labeled 250W)
GT20 Max equipped with 25AH+15AH dual batteries（Built-in Samsung brand battery）, you can easily conquer long-distance riding
Super powerful motorcycle grade hydraulic brakes will ensure you and your e-bike will slow down in the blink of an eye. These 2-piston brakes provide powerful stopping power in all riding conditions. 3.0mm thickness, 180mm diameter brake disc
When the trail gets steep, we got you covered. The GT20 Max comes standard with an 7-speed cassette to provide that extra power to smooth out even the gnarliest hills
The adventures don't need to end when the sun goes down; the GT20 Max comes with a bright LED Angel Eye headlight and tail light all with dual Turn signals to illuminate even the darkest paths
GT20 Max moto-inspired soft seat provides plenty of room to get into the perfect riding position. The extended seat will ensure you stay comfortable even on your longest rides, regardless of terrain or conditions
The Coswheel GT20 Max features adjustable double front suspension shocks with an inverted coil spring shock which can preload, compression, and rebound adjustments for better handling and a smooth ride and for optimal riding
The Coswheel GT20 Max features Thickened imported rubber tires that blend moto and bicycle tire construction ，more wear-resistant and puncture-resistant for improved traction, reduced road noise and increased stability，longer service life. Size 2.0*4.0 inches, suitable for snow, beach, mountain, road, mud all road shape,that can tackle even the toughest roads for your most resilient ride yet
Brand new waterproof and rust-proof chain, silver-whit
The GT20 Max carries a flowing headlights ,taillight along with dual turn signals to illuminate the darkest of roads
The GT20 Max comes standard with an
7-speed cassette to provide that extra
power to smooth out even the gnarliest hills.
Equipped with 60V 1500 rated power outputs max 2000 powerful power, Class 2/3 can unlock off-road mode, making climbing You'll experience the double power, provide you with an awesome riding experience(To comply with European regulations, the motor power can be labeled 250W)
GT20 Max equipped with 25AH+15AH dual batteries（Built-in Samsung brand battery）, you can easily conquer long-distance riding
Super powerful motorcycle grade hydraulic brakes will ensure you and your e-bike will slow down in the blink of an eye. These 2-piston brakes provide powerful stopping power in all riding conditions. 3.0mm thickness, 180mm diameter brake disc
When the trail gets steep, we got you covered. The GT20 Max comes standard with an 7-speed cassette to provide that extra power to smooth out even the gnarliest hills
The adventures don't need to end when the sun goes down; the GT20 Max comes with a bright LED Angel Eye headlight and tail light all with dual Turn signals to illuminate even the darkest paths
GT20 Max moto-inspired soft seat provides plenty of room to get into the perfect riding position. The extended seat will ensure you stay comfortable even on your longest rides, regardless of terrain or conditions
The Coswheel GT20 Max features adjustable double front suspension shocks with an inverted coil spring shock which can preload, compression, and rebound adjustments for better handling and a smooth ride and for optimal riding
The Coswheel GT20 Max features Thickened imported rubber tires that blend moto and bicycle tire construction ，more wear-resistant and puncture-resistant for improved traction, reduced road noise and increased stability，longer service life. Size 2.0*4.0 inches, suitable for snow, beach, mountain, road, mud all road shape,that can tackle even the toughest roads for your most resilient ride yet
Brand new waterproof and rust-proof chain, silver-whit
The GT20 Max carries a flowing headlights ,taillight along with dual turn signals to illuminate the darkest of roads
The GT20 Max comes standard with an
7-speed cassette to provide that extra
power to smooth out even the gnarliest hills.
Why Choose Coswheel GT20 Pro
light off-road electric fat bike
Coswheel GT20 Pro Focused on simplicity and ease,Designed for active lifestyles,the Shimano 7-speed derailleur and rigid aluminum full suspension fork make it a low-maintenance choice for city riders,and offer enhanced control and comfort for diverse terrains
Its Shimano 7-speed derailleur and rear motor deliver dynamic performance for riders who prefer versatility
The hydraulic front suspension fork, with the 20"x4.0" puncture protection tires, effectively cushions the shocks from diverse terrains. Riding this bike brings you much comfort and easiness
Yes, the 48V 25Ah+15Ah dual battery provides a reliable range of up to 233 km for extended adventures
Absolutely! It's designed to load up to 150kg,perfect for carrying camping gears and daily necessities
The front and rear lights ensure visibility during every ride, day or night, and the hydraulic disc brakes help stop the bike timely and quickly
Engineered for real-world challenges, the GT20 Pro`s rugged tires and strong motor provide stable, clean energy performance—whether you're tackling muddy roads or unpredictable terrain
Commute smarter with zero emissions. Coswheel GT20 Pro offers a smooth, efficient ride built for urban mobility—eco-conscious, stylish, and reliable for your everyday journeys
Escape the city and explore nature responsibly. With durable components and long-range battery, the GT20 Pro delivers a powerful, quiet ride that respects the environment and thrills the rider
